Deploy a Production-Ready ECS Server with Octo

September 11, 2025 · 8 min read

Maintainer

Ready to take your infrastructure to the next level?

Any advanced website requires backend and API servers, databases, and loads of other AWS resources. Setting up this infrastructure can be a daunting task. What if I told you that you could deploy a production-ready containerized server on AWS ECS with a load balancer, VPC, security groups, and multi-AZ setup in just a few minutes?

In this tutorial, we'll walk through deploying a scalable ECS server using Octo - a powerful infrastructure-as-code framework that makes complex cloud architectures surprisingly simple. By the end of this guide, you'll have a fully functional containerized application running behind an Application Load Balancer with enterprise-grade networking and security.

What We'll Accomplish

Today, we're going to:

Deploy a containerized server using AWS ECS with Fargate
Set up a complete VPC with public and private subnets across multiple availability zones
Configure an Application Load Balancer with health checks and target groups
Implement security groups and network isolation
Understand how Octo orchestrates complex multiservice infrastructure

The best part? You don't need to be a networking expert or container orchestration guru. Octo handles all the complex AWS resource relationships for you.

Prerequisites

Before we dive in, make sure you have the basics covered. If you haven't already, check out our installation guide to set up:

Node.js (version 22.x or higher)
AWS CLI (version 2.x or higher) with your credentials configured

Once you're all set up, we're ready to build some serious infrastructure! 🚀

Step 1: Create Your ECS Server App

Let's start by creating a new Octo application using the aws-ecs-server template. This template sets up a complete containerized server infrastructure with all the bells and whistles.

Open your terminal and run these commands:

# Create a new directory "my-ecs-server" in your current location
# and set up a new Octo app using the "aws-ecs-server" template
npx @quadnix/octo-build create-app -t aws-ecs-server -n my-ecs-server -p .

# Navigate into your new project
cd my-ecs-server

# Install the dependencies
npm install

That's it! Octo has just scaffolded a complete ECS infrastructure project for you. This template includes everything you need for a production-ready containerized application.

Step 2: Configure Your Environment

Before we can deploy our ECS infrastructure, we need to configure your AWS account. Create or edit the .env file in your project root:

# Your AWS account ID (you can find this in your AWS console)
AWS_ACCOUNT_ID=123456789123

tip

The ECS template is designed to be production-ready out of the box. It creates resources in us-east-1 with a specific VPC CIDR block (10.0.0.0/16). If you need to customize the region or networking, you can modify the module-definitions.ts file.

Step 3: Deploy Your ECS Infrastructure

Now for the exciting part - let's deploy your complete ECS infrastructure! This is where Octo really shows its power in orchestrating complex multiservice architectures.

# Build your Octo application
npm run build

# Deploy to AWS
npm start

Sit back and watch the magic happen! Octo will create:

VPC and Networking - A complete virtual private cloud with public and private subnets
ECS Cluster - A serverless Fargate cluster for running containers
Application Load Balancer - With health checks and target groups
Security Groups - Proper network isolation and access controls
Container Service - Running a sample echo server application
Multi-AZ Setup - High availability across multiple availability zones

Step 4: Access Your Live Server

Once the deployment is complete, you'll see the ALB DNS name in the HTML report output or in your AWS console. Your containerized server is now live and accessible through the load balancer!

Within the HTML report, you can find your ALB DNS name under @octo/alb=alb-region-module-app-region-east-qa-api-alb resource.
The DNSName key looks like qa-api-alb-<random_id>.us-east-1.elb.amazonaws.com.

Visit this URL in your browser:

http://qa-api-alb-<random_id>.us-east-1.elb.amazonaws.com

You should see a response from the echo server, confirming that your ECS infrastructure is working perfectly!

What Just Happened?

You might be wondering: "How did Octo create all the infrastructure?" Here's what happened behind the scenes:

Complete VPC Setup - Octo created a VPC with:

Public subnets in multiple AZs (with NAT gateways for outbound internet access)
Private subnets for your containers (with no direct internet access)
Proper routing tables and internet gateways

ECS Infrastructure - Octo set up:

An ECS cluster using Fargate (serverless containers)
A task definition for your container
An ECS service to manage container instances
Auto-scaling and health monitoring

Load Balancer Configuration - Octo configured:

An Application Load Balancer in public subnets
Target groups pointing to your ECS tasks
Health checks to ensure your containers are running
Listener rules for routing traffic

Security and Networking - Octo implemented:

Security groups allowing only necessary traffic
Network ACLs for additional security layers
Proper subnet isolation for security

Smart Infrastructure Management

If you run the app again, Octo will detect that your infrastructure already exists and won't recreate it unnecessarily. If you modify your container configuration and re-run, Octo will intelligently update only the changed components.

HTML Reports: Your Infrastructure Dashboard

After each deployment, Octo generates a comprehensive HTML report showing exactly what infrastructure was created. You'll find this report in your project root directory - open it in any web browser to see:

All AWS resources that were created
Resource relationships and dependencies
Configuration details for each component

This report is invaluable for understanding your infrastructure and ensuring everything was deployed correctly.

Customizing Your ECS Server

The template comes with a sample echo server, but you can easily customize it for your own application:

Changing the Container Image

Edit the module-definitions.ts file and modify the deployment configuration:

this.add(AwsEcsDeploymentModule, 'backend-deployment-v1-module', {
  deploymentContainerProperties: {
    cpu: 256, // Increase CPU if needed
    image: {
      command: 'npm start', // Your application command
      ports: [{ containerPort: 80, protocol: 'tcp' }], // Your app port
      uri: 'docker.io/strm/helloworld-http:latest', // <-- We changed the container image!
    },
    memory: 512, // Increase memory if needed
  },
  deploymentTag: 'v1',
  server: stub<Server>('${{backend-server-module.model.server}}'),
});

Scaling Your Application

You can easily scale your application by modifying the desired count:

this.add(AwsEcsExecutionModule, 'backend-v1-qa-execution-module', {
  // ... other configuration
  desiredCount: 3, // Scale to 3 instances
  // ... rest of configuration
});

info

Let's again rebuild and start the app using npm run build and npm start. The HTML report will show you the changes you made.

Heading in the AWS console, you will see that the task definition has been updated, and momentarily ECS server will start to pick up the new task definition. Wait for the new task to run, and then head over again to your ALB URL and refresh the page. You should not see responses coming from your new server!

Cleaning Up (When You're Done Experimenting)

When you're ready to clean up your resources (and avoid AWS charges), Octo makes it straightforward:

Edit your module-definitions.ts file
Comment out all modules except the app and account modules
Rebuild and run your app

private init(): void {
  this.add(SimpleAppModule, 'app-module', { name: 'aws-ecs-server' });
  this.add(AwsIniAccountModule, 'account-module', {
    accountId: config.AWS_ACCOUNT_ID,
    app: stub<App>('${{app-module.model.app}}'),
  });

  // Comment out all other modules to delete the infrastructure
  // this.add(AwsMultiAzRegionModule, 'region-module', { ... });
  // this.add(AwsEcsServerModule, 'backend-server-module', { ... });
  // ... comment out all other modules
}

Then run:

npm run build
npm start

warning

Deleting AWS resources takes time since Octo has to wait for confirmation from NAT Gateway and various other resources. AWS takes time to clean up resources and release IP addresses. In certain cases, the cleanup has been known to take >20 minutes.

Finally, delete your project directory:

rm -rf my-ecs-server

Why This Matters

What you just accomplished would typically require:

Deep understanding of VPC networking and subnet design
Knowledge of ECS task definitions and service configurations
Experience with Application Load Balancer setup and health checks
Understanding of security groups and network ACLs
Manual coordination of resource dependencies and timing

With Octo, you got all of this for free, plus:

Automatic resource orchestration and dependency management
Built-in best practices for security and networking
State management and change detection
Detailed reporting and audit trails
Easy cleanup and resource management

Conclusion

In just a few minutes, you've learned how to:

Deploy a complete ECS infrastructure with Octo's powerful templates
Understand complex AWS resource relationships and dependencies
Manage containerized applications with proper networking and security
Scale and customize your infrastructure as needed

Octo's philosophy is simple: complex infrastructure should be as manageable as your application code. By abstracting away the complexity of cloud resource orchestration, Octo lets you focus on what matters most - building great applications.

Ready to dive deeper? Check out our fundamentals documentation to learn more about how Octo works under the hood.

Happy containerizing! 🐳

Need Help?

If you ran into any issues during this tutorial, don't hesitate to reach out! You can find help links at the bottom of this page.

danger

Octo is still in its early phases, so if you encounter a bug creating or deleting resources, please help us by opening an issue on GitHub.

In worst case, to avoid unwanted AWS charges, reference the HTML report and manually delete the resources.
